The Objet260 Connex3 is your gateway to the world of multi-material color 3D printing. In a single print job, you can incorporate a wide range of material properties to vary translucency, rigidity, thermal resistance or color.

Single materials:
Vero family of opaque materials, including:

• VeroGray (RGD850)
• VeroBlue (RGD840)
• VeroBlackPlus (RGD875)
• VeroCyan
• VeroMagenta
• VeroYellow
• VeroBlack
• VeroWhitePlus
• Vero PureWhite, a brilliant white 20 percent brighter than VeroWhitePlus with twice the opacity

Digital Materials:
Hundreds of composite materials can be manufactured on the fly including:

• Vibrant blended colors in rigid opaque
• Translucent colored tints
• Rubber-like materials in a variety of Shore A values
• Digital ABS for durability, including blends with rubber
• Polypropylene-like materials with improved thermal resistance

Net build size:

• 255 x 252 x 200 mm (10.0 x 9.9 x 7.9 in.)

Layer thickness:

• Horizontal build layers as fine as 16 microns (0.0006 in.)

Build resolution:

• X-axis: 600 dpi; Y-axis: 600 dpi; Z-axis: 1600 dpi

Accuracy:

• Up to 200 microns for full model size (for rigid materials only, depending on geometry, build parameters and model orientation)
