System Physical Standard Configuration:
Type Details Descriptions
Product Form Default Orientation VR
Dimensions 271*193*150mm
LCD Screen Size 5''
Screen Resolution 720*1280
Battery  Type Lithium-ion polymer battery
Capacity 3.7V/2200mAh
Endurance 3 .5Hours
Performance Special battery for VR，Temperature control NTC10K，Batteries, resistance to high temperature of 70 °
System hardware configuration:
Type Details Descriptions
CPU  RK3126  Quardcore ARM Cortex-A7
Speed 1.3
GPU Type  Mali 400 MP2
Speed  400MHz
Multi-media
(Hardware decoding) Photo Viewer BMP, JPG, GIF, PNG
Video Format MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)
Audio Format MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license)
RAM Capacity 512MB /1G
ROM  Flash Capacity 8GB/16GB optional
G-sensor Built-in Gravity acceleration sensor
Network Connections:
Type Details Descriptions
WIFI WIFI module WIFI 2.4G/802.11b/g/n+BT 4.0(HS)/BT 2.1optional
3G External Not Suport
Ethernet Network MiNi USB switch to Ethernet Network Not Suport
lens parameters
Type Details Descriptions
Convex mirror lens diameter 40
material High transparent resin
mirror structure Low dispersion/aspheric
Refractive compensation 300 degrees myopia people naked eye see light
perspective ≥90°
Interface Configuration:
Type Details Descriptions
Memory card socket External memory Support outside enlarge( Maximum 32G)
USB interface Data transfer supportive USB OTG
Headphone jack  Music output ∮ 3.5mm standard headphone jack
DC connector Power  ∮ 2.5MM power connector
Keyboard Input device Wired / Wireless Supportive
Mouse Input device Wired / Wireless Supportive
Necessary Accessories:
Type Details Descriptions
3.5-inch headphone Standard Configuration Standard stereo headphones
Power adapter Standard Configuration 5V/2A
USB data cable Standard Configuration Connect to PC
USB patch cord Standard Configuration OTG to HOST
Software Configuration:
 Type Details Descriptions
Operating System Operating system version Andriod 5.1
Language Multi language support
FLASH FLASH Supports hardware decoding，FLASH 11
HTML5 Supports
Browser Browser
MoviePlayer MoviePlayer
FileBrowser FileBrowser
Settings Settings
