CM-2046 3 1/2 digits Digital AC/DC clamp meter with resistance testing function

• Features:
• 1. Clamp opens 52mm;
• 2. Large LCD display makes reading clear;
• 3. Full function protection, strong anti-interferential performance;
• 4. CE standard design, improves the safety of the test;
• 5. data hold;
• 6. Clamp light and backlight display;

Technical data

• DCV: 200mV/ 2V/ 20V/ 200V/ 1000V    ±(,0.5%+5)
• ACV: 200mV/ 2V/ 20V/ 200V/ 750V      ±(1.0%+5)
• DCA: 200A/1000A      ±(2.0%+5)
• ACA:  200A/1000A     ±(2.0%+5)
• Resistance: 200Ω/ 2kΩ/ 20kΩ/ 200kΩ /2MΩ/ 20MΩ    ±(0.8%+3)

Special functions:

• Diode test√
• Continuity test:Less than 50Ω±10Ω
• Low battery indicator:Approx. less than 2.4 V
• Data hold:Data hold/ Max value hold
• Auto power off:About 15 minutes
• Function protection√
• Clamp light√
• Backlight display√
• Input impedance:10MΩ
• Sampling rate:3 times/s
• AC frequency response:Current 50-60Hz/ voltage 50-400Hz
• Operation method:Auto or manual range
• Max display:1999
• Clamp opens:52mm
• Battery:3V (2*AAA battery)

General Characteristic:

• Meter weight:About 280g (including battery)
• Standard accessory:Test leads, battery, manual
• Standard packing:Gift box
• Carton size:55.5×26×38cm
• Standard QTY per carton:30pcs
• G.W per carton:26kg
