Digital Access Keypad

Model No.:

DK-2810

品牌:

APO

尺寸:

117(H) X 117(W) X 24(D) mm

Application:

Home and Office Door Entry

Number of Users:

1000 Codes and/or Cards

Operation Voltage:

12V DC

Proximity Card:

125KHz EM1400 & EM4200 EM Card

描述

联络供应商

The DK-2810 is an economy self-contained single relay output slim keypad.
It combines the functions of digital keypad and proximity EM card reader in one unit designed for stand alone operation.
It is an ideal keypad mainly for door strike in access control or arm-disarm control of an alarm system.
It can also be a programmable industrial timer (with the timing of 1 second to over 24 hours) for automatic operator systems.

Main features of DK-2810:

Stand alone electric lock in access control.
Compatible with fail-secure or fail-safe electric lock.
1,000 user pins and / or cards.
50 visitor codes programmable for one time; or valid for 1 to 99 hours.
Over 100 million combinations for user pins.
Super user code operates output relay, also makes system inhibit or resets inhibit.
Programmable intelligent egress button controls “going out” with delay, Warning and button contacting manners of momentary or holding contact.
Common user pin, group user pins & private user pins for working with the EM card for various levels of security enhancement.
On-off selectable for pacifier tone, standby flashing LED.
Output relay 1 N.C. & N.O. dry contacts, 5A / 24VDC maximum.
Extremely long programmable timer for output relay; 1 second to over 24 hours.
Tamper switch N.C. dry contact; 50mA / 12VDC.
Door bell button N.O. dry contact; 50mA / 12VDC.
Operating voltage: 12VDC nominal; 11-15VDC.
Operating current: 40 (quiescent) to 90mA (relay active).
Environment temperature: -20°C to +70°C.
Environment humidity: 5-95% relative humidity, non-condensing.
Operation environment & ingress protection: indoor only, IP-50.
ABS plastic housing.
Weight: 180gs.
Dimensions: 117 (H) x 117 (W) x 21 (D) mm.
Specifications are subject to change for modifications without notice.
Status: in mass production.
