- 2 years warranty.
- Magnification ratio: 6X, 10X, 16X, 25X, 40X.
- Eyepieces: 12.5X.
- Angle between eyepieces: 13°.
- Pupillary adjustment: 55mm~78mm.
- Diopter adjustment: ±6D.
- Field of view: 40X (Ø5.5mm), 25X (Ø8.5mm), 16X (Ø13.5mm), 10X (Ø22mm), 6X (Ø34.7mm).
- Slit width: continuously variable from 0 to 14mm (at 14mm, slit becomes a circle).
- Slit length: continuously variable from 1mm to 14mm.
- Lamp: 6V/20W halogen lamp.
- Slit angle: 0°-180° (continuously adjustable both vertical and horizontal).
- Slit inclination 4 step: 5°, 10°, 15°, 20°.
- Filters: thermal safety, UV, red-free, cobalt blue.
- Aperture diameters: Ø14mm, Ø10mm, Ø5mm, Ø3mm, Ø2mm, Ø1mm, Ø0.2mm.
- Longitudinal movement: 90mm.
- Lateral movement: 100mm.
- Vertical movement: 30mm.
- Fine base movement: 15mm.
- Vertical movement: 80mm.
- Fixation: green LED.
- Input voltage: 220V/110V~±10.
- Input frequency: 50Hz/60Hz.
- Power consumption: 30VA (max.).
- Output voltage: lamp 6V (continuously adjustable).
- Fixation 3V.
