ATM-300F (7- corrugation ridge ) or (9- corrugation ridge )
1、forming diameter:¢80――¢350mm
2、pipe length 500――6000mm(no limit, it can make any length )
3、thickness:0.050—0.15mm(aluminum), 0.035—0.10mm(stainless steel)
4、strip width:60 mm
5、speed:1-70m/min (it can be adjusted)
6、system control:with LCD screen, transducer and PLC control, Automatic cut the pipe to length, And then Automatic compress the pipe to length
7、main powe1.5KW, 220volt, single phase, 50 Hz
8、weight:about 1000kg
9、overall size:1860×1150×1330mm and 5000x700x1000mm
10,for material: aluminum foil, copper foil, stainless steel , galvanization steel
