LED Driver
生产所需时间:
25 日
产品型号:
XSD24W350LS
品牌名称:
GWD
颜色:
White
尺寸:
131 x 44 x 25mm
港口:
Guangzhou
付款方式:
T/T
最低订购数量:
1,000 piece(s)
是否有包装:
有
描述
联络供应商
描述
This LED driver is able to driver a broad range of LED lighting equipment. The functional LED driver can greatly enhance lighting efficiency. The compact LED driver can be easily installed and replaced.
Main Features:
Model / Input / Voltage /Constant Current /Rated Load / Ta /Tc /Typical Efficiency
Standby power/ Power Factor /Short CircuitProtection Protection /Class Dimention
XSD24W350LS 220V-240V~50/60Hz DC350mA
50V-70V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W420LS 220V-240V~50/60Hz DC420mA
46V-58V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W550LS 220V-240V~50/60Hz DC550mA
38V-44V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W700LS 220V-240V~50/60Hz DC700mA
30V-35V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W850LS 220V-240V~50/60Hz DC850mA
25V-29V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W1050LS 220V-240V~50/60Hz DC1050mA
18V-23V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W1300LS 220V-240V~50/60Hz DC1300mA
15V-19V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD30W700LS 220V-240V~50/60Hz DC700mA
36V-43V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD36W700LS 220V-240V~50/60Hz DC700mA
43-52V 30-36W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD36W850LS 220V-240V~50/60Hz DC850mA
36-43V 30-36W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD36W1050LS 220V-240V~50/60Hz DC1050mA
30-35V 30-36W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD36W1300LS 220V-240V~50/60Hz DC1300mA
23-28V 30-36W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD36W1500LS 220V-240V~50/60Hz DC1500mA
23-28V 30-36W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
Main Features:
- Constant current
- With SCP, OTP and OVP function
- Operating temperature -40℃~60℃
- Comply with safety of UL8750, CQC and CE
- Comply with EMC standard
- MTBF:550000hrs
- Timing and brightness dimmer control or remote intelligent dimming
- Stable operation, High reliability, Multifuntion protection
Model / Input / Voltage /Constant Current /Rated Load / Ta /Tc /Typical Efficiency
Standby power/ Power Factor /Short CircuitProtection Protection /Class Dimention
XSD24W350LS 220V-240V~50/60Hz DC350mA
50V-70V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W420LS 220V-240V~50/60Hz DC420mA
46V-58V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W550LS 220V-240V~50/60Hz DC550mA
38V-44V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W700LS 220V-240V~50/60Hz DC700mA
30V-35V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W850LS 220V-240V~50/60Hz DC850mA
25V-29V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W1050LS 220V-240V~50/60Hz DC1050mA
18V-23V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD24W1300LS 220V-240V~50/60Hz DC1300mA
15V-19V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD30W700LS 220V-240V~50/60Hz DC700mA
36V-43V 20-24W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD36W700LS 220V-240V~50/60Hz DC700mA
43-52V 30-36W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD36W850LS 220V-240V~50/60Hz DC850mA
36-43V 30-36W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD36W1050LS 220V-240V~50/60Hz DC1050mA
30-35V 30-36W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD36W1300LS 220V-240V~50/60Hz DC1300mA
23-28V 30-36W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
XSD36W1500LS 220V-240V~50/60Hz DC1500mA
23-28V 30-36W 50℃ 85℃ >75% <0.1W >0.82 √ IP 20 131*44*25
