General: large field flat panel detector, integrated digital acquisition system with flat panel monitor within stand, small footprint for van installation

Generator: high frequency, 3 kW, 20-30 kV, 0-500 mAs, up to 100 mA

X-ray tube: Mo, focal spot 0.1 mm and 0.3 mm, rotating anode, 40 kHU /min

Gantry: rotation +180 to -165 degree, floor to detector distance 65 cm-150 cm, source-detector distance 66 cm, magnification 1.5, compression 200 N

Exposure Control: manual and automatic

Filter: Mo

Flat Panel Detector: 25cm x 30 cm, pixel size 42 µm, DQE at 0 lp/mm 60%

Digital Acquisition System: storage 8,000 images, preview image <20 sec, zoom, roam, invert, multi-format, thickness equalization, image annotation

Connectivity: auto send, auto print, DICOM SEND, Query, work list, storage, print

Image Display: 2 MB LCD B&W monitor on stand
