This main controller is the center of the guest room control system. Equipped with a 24MHz eight-digit CPU with a 32KB RAM capacity, the high-tech device offers ample control terms. The guest room controller separates strong and weak current wires and avoids the interference of signals. The main board adopts the SMT productive technology and foreign relay. The controller has been tested under high temperature, moisture and high load to ensure the product can work well in an adverse environment.

• Working voltage: AC 210V-230V.
• Working temperature: 0°C-+65.0°C
• Power dissipation: P<5W.
• Working humidity: ≤5-90% RH.
• Communication term: Ethernet network superstratum TCP/IP, RS485 trunk in guest room
• Output term: relay output.
• Input term: optical coupler input.
• Output circuit: 15A, 1 circuit; 10A, 15 circuits; 3A, 3 circuits; 1A, 3circuits.
• Input circuit: 28 circuits, low current.
• Strong current connection term: fence circuit terminal.
• Low current connection term: European terminal connection.
• Uplink communication (TCP/IP): RJ45 slots.
• Downlink communication (RS485): European terminal connection.
• Configuration size: (L)360mm x (W)260mm x (H)80mm.
