Supplier: Shenzhen Grande Electronics

Layers: 6

PCB：FR-4/1.6mm, 1oz finished copper

Application: Music Instrument PCB Assembly Service-Grande PCBA

Surface Treatment: ENIG

PCBA Lead time:3-4 weeks

Packing: Anti-static bag and compartmental packing

Twist: ＜0.75%

【Description】

1, PCBA turnkey solution for Analysis Instrument PCB Assembly Service- Grande PCBA.

2, PCB Assembly, PCB fabrication / PCB layout, PCB re-layout.

3, Electronic Manufacturing Service.

4, SMT&DIP&PTH&BGA.

5, Components Sourcing.

6, Quick PCBA prototype.

7, X-ray test, the Internal Circuit Test (ICT) , Function Test (FCT)

8, Sample and small batch order are accepted.

PCBA Service

Customer offers: Gerber file, PCB Specification, BOM and Assembly Drawing.

Full-turnkey PCBA: 1-30Layers PCB, Components Sourcing, SMT, PCBA testing, PCBA Aging test, PCBA Packing and PCBA Shipping.

PCBA Quality Assurance

1, Certifications: UL, SGS, TUV, BV, ROHS, ISO9001: 2008, TS16949: 2008

2, 7 lines dust-proof SMT lines and DIP lines.

3, All line workers wear anti-static and dust-proof clothing.

4, All operators should pass strictly training before they start work.

5, SMT Equipment：solder paste printer in Jidakang,, Mounter in Panasonic, Re-flow, Wave Soldering and Semi-auto DIP

6, PCBA Test Equipment: ORT, Constant temperature and humidity chamber，3D CMM，X-Ray.

7, PCBA Test：ICT, Functional Circuit Test and X-ray test.

8, Package Processed：

0402, 0603, 0805, 1206, 1608, 2125, 3216

Micro QFP 0.2mm

Flip-chip, BGA, Connectors

BGA Ball Pitch=0.2mm

9, Each workstation in accordance with the SOP

10, Materials：FR-4, FPC, Aluminum，High TG，Halogen-Free, HF, CEM-1, CEM-3, FR-1, 94-V0 and so on.

11, Material Brand：KB, SHENGYI, NANYA and so on.

PCBA Lead Time

PCBA prototype: 7-10 working days after contract signed and EQ confirmed.

Mass production: partial delivery according to the customer’s requirement.
