Advantages:
1)Two function in One:EAS+RFID.
2)small and convenient, goods traceability function, can identify, implement inventory and management.
3)increase the function of RFID on existing security design, only need to increase the inventory of reading and writing equipment, keeping the EAS devices, reduce the update cost.
Specification:
Protocol:EPC C1G2 (18000-6C)
Chip:impinj Monza5
Dimension:45*10*2MM
EPC : 128bit
Working Temperature:-20°C to +55°C
RFID Frequency:860-960MHz
EAS Frequency:58KHZ
RFID reading range:1m(9dbi读写器)
EAS read range: 1.2m
Material:ABS
Certificates: RoHS CE
Dimension:
Label Dimensions(标签尺寸)
Label length/长 ..........45.21mm ± 0.5mm(1.78”±0.020”)
Label width/宽 ..........10.67mm ± 0.5mm(0.420”±0.020”)
Label thickness/不含底纸厚度
(excluding liner)...............Maximum1.89mm(0.074”)
Label thickness/含底纸厚度
(including liner)..................Maximum2.00mm(.079”)
