Supplier: Shenzhen Grande Electronics

Layers:4

Application: Printing Machine Grande PCB Assembly | One-Stop PCB Solutions Supplier

PCB:FR4/1.6mm/2oz

Min Via: 0.2mm

Surface Treatment: HASL

PCBA Lead time: 3-4 weeks

Testing: 100% E-test

Standard Warp:<0.75%

[Description]

1, Turnkey solution for Printing Machine Grande PCB Assembly | One-Stop PCB Solutions Supplier.

2, PCB Assembly, PCB fabrication / PCB layout, PCB Reversing.

3,  Full Bespoke PCBA/ OEM/ EMS(Electronics Manufacturing Services).

4, SMT&DIP&PTH&BGA.

5, Components Sourcing.

6, Quick PCBA prototype.

7, X-ray test, ICT and Functional Circuit Test.

8, Sample and small batch order are accepted.

PCBA Service

Customer offers: Gerber file, PCB Specification, BOM and Assembly Drawing.

Full-turnkey PCBA: 1-30Layers PCB, Components Sourcing, SMT, PCBA testing, PCBA Aging test, PCBA Packing and PCBA Shipping.

PCBA Quality Assurance

1, Certifications: UL, SGS, TUV, BV, ROHS, ISO9001: 2008, TS16949: 2008

2, 7 lines dust-proof SMT lines and DIP lines.

3, All line works wear anti-static and dust-proof clothing.

4, All operators should pass strictly training before they start work.

5, SMT Equipment:solder paste printer in Jidakang,, Mounter in Panasonic, Re-flow, Wave Soldering, Semi-auto DIP

6, PCBA Test Equipment: ORT, Constant temperature and humidity chamber,3D CMM,X-Ray.

7, PCBA Test:ICT, Functional Circuit Test and X-ray test.

8, Package Processed:

0402, 0603, 0805, 1206, 1608, 2125, 3216

Micro QFP 0.2mm

Flip-chip, BGA, Connectors

BGA Ball Pitch=0.2mm

9, Each workstation in accordance with the SOP

10, Materials:FR-4, FPC, Aluminum,High TG,Halogen-Free, HF, CEM-1, CEM-3, FR-1, 94-V0 and so on.

11, Material Brand:KB, SHENGYI, NANYA and so on.

PCBA Lead Time

PCBA prototype: 7-10 working days after contract signed and EQ confirmed.

Mass production: partial delivery according to the customer’s requirement.
