Main technical parameters
1. Type of measurement : electroluminescence
2. Module type: multi, mono
3. Module dimensions: max. 2000mmX1200mm min. 1600mm X 800mm
4. Module face :down
5.Pixel : 4928×3264 pixels
6.Image resolution:400µm/pixel
7. Speed: ≤45s.(The match of completed line is essential)
8. Transmission height: 950 +/- 30mm
9.String & module parameters: microcrack, contamination, sintering defect, material defect, broken finger, low-efficiency solar cell area
