Features
● Low cost
● 5 standard sizes
● Split core design, safer, easier installation, and
portable
Applications
● Current, power, energy, monitoring devices
● Relay protection devices
● Power Factor Correction devices
Specifications
● Rated Primary current: 100-5000Aac
● Rated Secondary current:5 or 1Aac
● Rated load: 1, 2.5, 5.0, 10, 30VA
● Accuracy: 0.5, 1.0, 3.0 Class
● Rated Short-time thermal current (Ith):20In
● Rated Dynamic current (Idyn):2.5Ith
● Case Material: UL flame retardant rating 94-V0
● Highest Voltage for Equipment Um (rms):720 Vac
● Rated Power-Frequency Withstand Voltage
(rms):3,000 Vac
● Frequency Range:50/60Hz
● Operating Temperature: -15℃ to 50℃
● Standard:IEC 60044-1
● RoHS compliant
● CE&ETL approved
● Accessories:Supplied with feet for base
mounting if required
