• ISO 9001:2000; ISO 14001:2004 certified.
• RoHS complaint SGS certified.
• Frequency range 3MHz to 80MHz.
• Stability +/-3ppm to 100ppm.
• Competitive pricing.

Product specifications:

• Frequency range: 7.600MHz~110.000MHz.
• Mode of oscillation: 7.600MHz~48.000MHz fundamental; 30.000MHz~110.000MHz third overtone.
• Frequency tolerance at 25°C: +/-50ppm max. (+/-5ppm; +/-10ppm; +/-30ppm available).
• Frequency stability over temperature: +/-50ppm max. (+/-5ppm; +/-10ppm; +/-30ppm available).
• Operating temperature range: -10°C~60°C standard, -40°C~85°C extended.
• Storage temperature range: -40°C~85°C.
• Aging: +/-3ppm/year max.
• Load capacitance: 8 PF~32 PF or series.
• Shunt capacitance: 4.0 PF max.
• Drive level: 0.01µW~100µW.
• Reflow conditions: 260°C for 10s max., 2 reflows max.

Resistance of series resonance (ESR):

• 7.600~16.000 (MHz): fundamental 80 ohm max.
• 16.001~30.000 (MHz): fundamental 50 ohm max.
• 30.001~50.000 (MHz): third overtone 100 ohm max.
• 50.001~110.000 (MHz): third overtone 90 ohm max.
