5 Terminal Square Trimming Potentiometer Features
- (Multiturn/ Cermet/ Industrial/ Sealed)
- (5 Terminal Styles)
5 Terminal Square Trimming Potentiometer Electrical Characteristics
- Standard Resistance Range 10Ω - 5MΩ
- Resistance Tolerance ±10% (±20% only for 10 ohm)
- Absolute Minimum Resistance ≤1% R or 2Ω
- Contact Resistance Variation CRV≤1%or 3Ω
- Insulation Resistance R1≥1GΩ(500V AC)
- Withstand Voltage 640V AC
- Effective Travel 28 turns nom
