Amplifier Installation Wiring Kit 4 & 8 Gauge
Share this page
US $3.38 - US $12.20
Production Lead Time:
40-45 day(s)
Shipping Method:
by sea
Brand:
OEM
Model No.:
SR-30
Material:
Copper/Brass or CCA
Package:
Blister or Gift box or PE bag
Description
Contact Supplier
Description

 A Car Amplifier Wiring Kit Helps You Make Connections and Brings Power To Your Radio, Subwoofers and Speakers

  • 18' 4 AWG Blue KCA Kable (CCA) Power Wire
  • 3' 4 AWG Black KCA Kable (CCA) Ground Wire
  • Inline fuse holder with 80A fuse
  • 5 Meter Bassik Twisted Pair OFC RCA Cable
  • 20 Feet Bassik 14 AWG CCA speaker wire
  • 5 Meter Blue Remote / Turn one wire
  • 2 gold plated 4 gauge ring terminals, 2 gold plated 4 gauge spade terminals
  • grommets and wire ties


BassiC Twisted Pair 2 Channel RCA Cable


Our BassiC RCA is just that, a straight forward design.

Bassik RCA Features include:

  • Oxygen Free Copper construction
  • Twisted Pair Geometry for noise rejection
  • Ultra Flex, soft touch PVC allows this cable to fit in tight places
  • Easy channel identification
  • Gold Plated RCA Connectors.




  • Using American Wire Gauge standards, the gauge of stranded wire is determined by the total area of the conductor.
  • To calculate this you would take the area of each strand and add it together. This area, in square mm, then determines gauge.
  • Diameter is not as critical with stranded wire, this is due to the tiny air gaps between each strand. Diameter may fluctuate with strand size and how tightly wound the rope of the cable is.
  • The smaller the number, the larger the wire, until you reach zero or aught (0). From zero, you then have double aught (00), three aught (000) and so on.
  • Based on AWG, the true gauge of this cable is #3, larger than traditional 4 gauge



  • We've compared several popular 4 gauge amp kits from other manufactures. The above chart displays the manufacture and the calculated gauge based on area.
  • All cables tested were labeled as 4 gauge. The X axis indicates gauge by area and where each cable's measurement placed itself on the American Wire Gauge scale.
  • Several brands barely reached the required area of 8 gauge.


Every amp installation kit clearly states these critical specs:

  • Wire type - CCA or OFC
These materials are commonly used, but not commonly stated when shopping online. Know what you are purchasing. Both metals are capable of performing up to their rated loads.
  • American Wire Gauge
Wire gauge is crucial to powering your system correctly. Undersized cable will create unsafe conditions and may shorten your amplifier's life
