PSR Controller & Power Switch
Production Lead Time:
3 day(s)
Model No.:
SF6010L
Brand:
SiFirst
Colour:
Black
Minimum Order Quantity:
10 piece(s)
Description
Contact Supplier
Description
Features:
- Proprietary "Zero-Output Statup "Control.
- Proprietary "Smart Output Short Protection".
- FB short protection.
- Direct drive of low cost BJT.
- Wide VDD operating range (7V to 24V).
- Less than 70mW standby power.
- Proprietary NC-Cap/PSR TM (primary side regulation) control without External Compensation/Filtering Capacitor needed.
- ±5% CC and CV Precision.
- Proprietary cable drop compensation.
- Low standby power under 70mW.
- Compensate for transformer inductance tolerances.
- All pins floating protection.
- Cycle-by-cycle current limiting.
- Built-in leading edge blanking (LEB).
- Built-in soft start.
- Output over voltage protection.
- VDD OVP & clamp.
- VDD under voltage lockout (UVLO).
Applications:
- Battery chargers for cellular phones, cordless phones, PAD, digital cameras, etc.
- Replaces linear transformer and RCC SMPS.
- Small power adapter.
- AC/DC LED lighting.
