Places of application:

• Façade of buildings such as theatres, hotels, venues for conferences and exhibitions.

Product characteristics:

• Relatively high transmittance, uniform light-mixing effect.
• High-performance LED chips of international first-class brands.
• Large-angle light-emitting arc face brings about wider sight range.
• Multiple-layer protection ensures more reliable water-proof performance of lamps.
• Simple mounting support is applicable to more extensive install.

Lamp materials:

• Aluminium alloy lamp body, tempered glass cover, polyester powder coating on surface.

Performance parameters:

• LED brand: Cree.
• Single LED power: 0.25W.
• Lamp service life: 20000hr.
• LED color: RGB, red, yellow, blue, green, white.
• Effects: RGB color-changing, flowing, chasing, 256 grades brightness.
• Beam angle: 10 x 30°.
• Working power supply: 20mA constant-current driver.
• Protection class: IP65.
• Electric safety class: DC24V Ⅲ type, AC220V Ⅰ type.
• Power line: DC24V 2 x 1.0 mm2 cable wire.
• AC220V 3 x 0.75mm2 cable wire.
• Signal line: 3 x 0.75mm2 signal cable with connectors.
• Control method: standard DMX512.
• Ambient temperature: -25℃～+45℃.
