0.39 inch AMOLED FHD 1920 x1080 MIPI/Type-c Interface OLED Display for AR/VR Head mounted/Near-Eye Displays

Microtech Technology Co Ltd

Enquire

Compare & Bulk Enquire

US $2.00 - US $3.00

Production Lead Time:

25-45 day(s)

Shipping Method:

Support Express · Sea freight · Land freight · Air freight

Brand:

Microtech

Model No.:

MTL0039FD02A-V1

Customised:

Yes

Size:

0.39inch

Description

Contact Supplier

MTL0039FD02A-V1 is a 0.39 inch（1 cm) diagonal, FHD resolution(1920 x1080), active matrix color
OLED (Organic Light Emitting Display)panel module based on single crystal silicon backplane . The pixel
circuits and driving IC are integrated on the silicon backplane to get the compact size and very low power
consumption.
(Potential applications: Virtual Reality application（AR/VR）, Head mounted displays, Near-Eye Displays etc.)Small-size, high resolution 0.39 FHD Display PPI=5644
 AP Operated Resolution (8*M, M=40~240) x RGB x (8*N, N=30~135)
 Full color mode，16.7M colors
 Fast response
 Thin and light in weight
 Color enhancement, Sharpness enhancement
 High contrast mode
 High fluency mode
 Power-saving (PS) mode
 Scan direction selection, up or down
 Interface，Support MIPI only or MIPI(data)+I2C(CMD)
