1.78 inch AMOLED touch screen 368*448 SPI interface apply to smart watch

US $8.00 - US $20.00

Production Lead Time:

25-45 day(s)

Shipping Method:

Support Express·Sea freight·Land freight·Air freight

Brand:

Microtech

Model No.:

MTL0178VV03A-V1

Customised:

Yes

Size:

1.78inch

Description

Contact Supplier

1) Display Color: 16.7M colors (24bits)
2) Display Format: 1.78 Inch 368×448
3) Interface: QAD-SPI
4) Driver IC: XM80240
5) Power IC: BV6802
6) Polarizer: Hard Coating Polarizer

GENERAL INFORMATION

Item	Contents	Unit
Display Mode	AMOLED	/
LTPS Glass Outline (WDH)	45.2 x 34.4	mm
Encapsulation Glass Outline (WDH)	37.99 x 30.6	mm
Active area	34.9 x 28.7	mm
Number of Dots	368x3(RGB)x448	/
Diagonal Inch	1.78	inch
Pixel pitch (WDH)	78 x 78	um
Glass Thickness	0.2 (LTPS) 0.205 (Encap) 0.678(Total)	mm

TP General Specifications
Dimension description

Item	Contents	Tolerance
CG shape size	45.234.41.5	±0.05
Visual area size	35.35*29.1	±0.15
Sensor shape size	/	±0.15

Structural description

structure	Material Science	Remarks
Layer 1	CG	1.5mm Glass,
Layer 2	OCA	Thickness 0.175
Layer 3	Film	/

TP Electricity1

Touch control performance	G+F single point + gesture
Channel Number	TX7*RX8
Touch IC	FT3168
