Electrical specification

• Input voltage range: 90~264Vac
• Frequency: 50/60Hz
• AC current: 0.8A
• Inrush current: 30A/230Vac
• Leakage current: 0.25mA/240Vac
• AC connector: Euro two round pin
• Output voltage: 12.0Vdc
• Output voltage range: 11.4 - 12.6Vdc
• Output current: 3.0A
• Line regulation: ±1%
• Load regulation: ±5%
• Efficiency: meet energy star level V(EUP)
• No load power consumption <0.3W
• Protection: overload protection, short circuit protection

Environment

• Working temp.: 0~40℃
• Working humidity: 20%~90% RH non-condensing
• Storage temp. & humidity: -20℃~85℃, 10%~95% RH

Safety approval

• Approved by UL, CE, FCC, C-TICK

Dimension

• 105mm x 45mm x 27.8mm (L x W x H)
