15.6 inch LCD TFT 1920*1080 Panel eDP Interface LCD Modules with Backlight-driving LED Controller | Parts, Components & Electrical Supplies

Microtech Technology Co Ltd

15.6 inch LCD TFT 1920*1080 Panel eDP Interface LCD Modules with Backlight-driving LED Controller

US $15.00 - US $30.00

Production Lead Time:

25-45 day(s)

Shipping Method:

Support Express · Sea freight · Land freight · Air freight

Model No.:

MTF156FD02A-V1

Brand:

Microtech-lcd

Customised:

Yes

Size:

15.6inch

Description

Contact Supplier

15.6 inch LCD TFT 1920*1080 panel eDP interface LCD Modules with Backlight-driving LED controller

Parameter	Specification	Unit	Remarks
Display size	15.6 (Diagonal)	pixels
	394.38 (Diagonal)	mm
Number of pixels	344.16(H) *193.59(V)	mm
Pixel Format	1920(H) × 1080(V) （1pixel = R + G + B dot）	pixels
Pixel pitch	0.17925(H) x 0.17925 (V)	mm
Pixel configuration	R, G, B vertical stripe	colors
Display mode	Normally Black
Driving scheme	FFS
Power Consumption	0.561	w
Surface treatment of front polarizer	Anti-glarecoating: (3H)
Back-light	Lower edge side, 1-LED Lighting Bar type
