15W PD Fast Charge
Model No.:
S015BU
Brand:
Ten Pao
Customised:
Yes
Description
Contact Supplier
Description
Main Technical Features：
1. Flyback QR circuit topology
2. 15W maximum, single USB-C port
3. Meets the requirements of EU VI energy efficiency
4. Meets Global EMC requirement
5. Most competitive design for cost
| Model Series | S015BU | |
| Input Parameter | ||
| Rated Input Voltage | 100-240VAC | |
| Max Input Voltage | 90-264VAC | |
| Input Line Frequency | 50-60HZ | |
| Maxmium Efficiency | 85% | |
| AC Plug | Fixed Pin(CN/US/UK/EU/Aus) | |
| Output Parameter | ||
| Output Receptacle | USB-C | |
| Output Voltage | 5V | |
| Output Current | 1-3A | |
| Output Power | Max 15W | |
| Size | 50*40*25mm | |
| Safety standard | UL62368,EN62368,FCC PART 15,EN55032,GB4943.1 | |
| Safety Certificate | Fulfill the UL/CUL,CB/CE,CCC,FCC and etc. | |
