16.8V5A Li-ion Charger for E-Bike and Electric Tools
Model No.:
16.8V5A
Brand:
Modiary
Colour:
Black
Size:
147X65X34mm
Port:
Shenzhen
Type of Payment:
T/T in advance
Minimum Order Quantity:
500pcs
Package:
Yes
Customised:
Yes
Description
Contact Supplier
Description
Technical data
Max. Output power: 60W
Input voltage: 100-240V AC
Output :16.8V5A
Line frequency: 50-60Hz
Efficiency(at 100% load): >=80%
Ripple: <=1%*Vo
Protection
Short circuit protection
Over voltage protection
Over current protection
Reverse polarity connect protection
General specification
3-step charging control (pre-charge-CC-CV)
Option: a) NTC inside
b) 100% cut off when battery fully charged
Dual color LED indicator:(Charging:Red; Fully charged or no load:Green)
Light weight and compact
High efficiency and low power consumption
Reliability specification
Insulation class: II
Electrical safety: EN60335, IEC60335,
EMC standard: EN55014-1, EN55014-2, FCC Part15
Max. Output power: 60W
Input voltage: 100-240V AC
Output :16.8V5A
Line frequency: 50-60Hz
Efficiency(at 100% load): >=80%
Ripple: <=1%*Vo
Protection
Short circuit protection
Over voltage protection
Over current protection
Reverse polarity connect protection
General specification
3-step charging control (pre-charge-CC-CV)
Option: a) NTC inside
b) 100% cut off when battery fully charged
Dual color LED indicator:(Charging:Red; Fully charged or no load:Green)
Light weight and compact
High efficiency and low power consumption
Reliability specification
Insulation class: II
Electrical safety: EN60335, IEC60335,
EMC standard: EN55014-1, EN55014-2, FCC Part15
