Provide stable power output for medical equipment with this 24W medical power adapter. It supports a wide range of AC input voltage and offers protection against short circuit, over current and over voltage. This medical power adapter comes with interchangeable AC plugs and is suitable for medical equipment up to class BF.

Features:

• Wide range of AC input voltage: 90 - 264V AC
• Protections against short circuit/over current/over voltage.
• 2MOPP input to output isolation.
• Suitable for medical equipment up to class BF.
• DOE affiance level VI CoC-V5 Tier2.
• leakage current lower 10ua (8.1-14V), and lower 50ua (6.1A-8V&14V-24V).
• Up to 5,000 operating altitude.
• Interchangeable AC plugs.

Technical data:

• Input voltage: 90-264V AC.
• Input current: 500mA.
• Output voltage range:  ±5%.
• Standby power: 0.075W.
• Average efficiency: CoC-V5 Tier2.
• Reliability: at 25°C ambient temperature, maximum load work 50,000 hours MTBF (according to MIL - HDBK - 217 standard).

Environmental requirement:

• Operating temperature: 0 - 40°C.
• Storage temperature: -20 - 60°C.
• Humidity enrichment conditions, humidity: 10-90%.

Safety standard:

• Medical: CB/IEC60601, UL/ES60601, TUV/EN60601.
• ITE: CB/IEC60950, UL/EN60950, AS/NZS60950, TUV/EN60950.
• Applications: portable medical devices/medical equipment/ITE devices.
