Back Light D-LED(BOE/PANDA)
solution MST
Interface LED
Size & Aspect Ratio31.5"(16:9)
Pixel Pitch0.17025(H) X 0.51075(V)
Active area697.68 x 392.26 mm (WxH)
Max. Color16.7M
Resolution1366 x 768
Contrast Ratio3000:1
Brightness400cd/㎡
View Angle(CR≥10)176°(H)/176°(V)
LED backlight life100,000hours
Response Time(Typ)6.5ms
TV Standard & Set Up
Tunerx 1
DTV SYSTMDVB-T(MPEG2,MPEG4,MHEG5)EPG、Subtitle
Video System PAL/SECAM/NTSC-3.58,NTSC-4.43,PAL-60
Sound System B/G, D/K, I,L,L',M.N
Audio
Sound Effect MTS, Spatial Stereo, Dynamic Bass
Sound output10W X2
SOUND SYSTEMB/G;D/K;I;L/L
STEREO SYSTEMYES
NICAMYES
VIDEO
TV SYSTEM pal/secam/NTSC
DTV SYSTEMDVB-T(MPEG2,MPEG4,MHEG5)
HDTV Compatible 480p, 576p, 720p, 1080i,1080P
Teletext(Page)500PAGES
Deinterlace / Comb filter3D
3D Video Noise Reduction YES
PIP/POPNO
OSD LANGUAGE English/French/German/Spanish/Italian/Dutch/Portuguese
Connectors
AVx2
S-VIDEOx1
SCartx1optional
VGAx1
HDMIx2;x3 optional
DVINO
Coax digital outputx1
Stereo mini jack inputx1
RCA inputx2
CI slotx1 optional
USB X1(USB PVR,MPEG1, MPEG2,MP3, WMA,JPEG);MPEG4 VIDEO optional
Analog tuner x1
DVB-T optional
ATSC tuner optional
DVDNO
YPbPr or YCbCr (COMPONENT)x1
Headphonex1
other Features
Auto Power off yes
Sleep Timer yes
Clock yes
Consumption Standby: 1 watt/ Operating: less than 100Watt
Safety CE/ROHS/FCC
UNIT/Carton Size850X130X530mm
Net/Gross Weight9kg/11kg
Loading Capacity 20"/40"/40"HQ448pcs/924pcs/1150
Minimum order Qty (OEM)1x40HQ
wall-mount (Extra cost)USD2
