Features:

• Supply Voltage: 90-305Vac or 127-250Vdc
• 100,000Hour Life @ Tc=75C
• 5 Year Warranty
• AirsetTM NFC Programmability
• 1% 0-10V/PWM/Time/DALI Dimmable
• Isolated Dimming Input
• Dim Off with 0.5W Standby Power (Optional)
• 12V 300mA Auxiliary Power (Optional)
• Low Inrush Current
• Class II (Optional)
• UL Type TL, Class 2
• ENEC/CB/CCC SELV Output
• Safety according to EN 61347-1, 61347-2-3, 61347-2-13, 62384

Technical Data :

• Input Voltage: 90～305Vac or 127V-250Vdc
• Input Frequency: 47～63Hz
• Power Factor: >0.9@60-100%load, refer to PF vs. Load curve
• THD: <15%@60-100%load, refer to THD vs. Load curve
• Input Current: 1.8 Amax@110Vac & Full-Load, 0.9Amax@220Vac & Full-Load
• Inrush Current: 2A peak, 1.2ms duration, <0.025A2s@230Vac, Cold Start; 4A peak, 1.3ms duration, <0. 05A2s@277Vac, Cold Start
• Leakage Current: 1mA max @277Vac 60Hz, UL8750, 0.75mAmax @220Vac 50Hz, IEC61347-1
• Input Under Voltage: Shut down and auto-recovery
• Surge Protection: Line to line 4kV, line to ground 6kV, IEC 61000-4-5
• Current Accuracy: ±5%Io
• Ripple Current: Ip-p:5%Io max
• Setup Time: 1.2s max
• Overshoot: 10% Io max & LED Load
• Output Over Voltage: 120% Vomax, typ.
• Short Circuit: Auto recovery. The output recovers when short is removed.
• Over Temperature: Lower the output current when Tc≧105±10℃; Auto Recovery When Tc≦70±10℃
• Auxiliary Power (Vaux)  : 12V+/-5%, 200mA max
• Operating Temperature: Case Temperature Tc=-30℃~+90℃ ；10%RH～100%RH
• Storage Temperature: -30℃～+85℃； 5%RH～100%RH
• MTBF: ≥350,000 hours, 50℃ case  temperature (MIL-HDBK-217F)
• Lifetime: ≥100,000 hours, 75℃ case  temperature, refer to life vs. Tc curve
• Case Temperature: 90℃ max, marked in the Tc point of label
• Dimensions: 14.88x1.18x0.82 by inch, 378 x 30 x 21 by mm

Notes:  Unless specified, all the test results are measured in 25℃ room temperature.
* marked items are optional and contact with sales people to get the functions.
