    5V 2A USB Power Charger
    Share this page
    Model No.:
    XHY050200UCC
    Brand:
    XHY
    Colour:
    Black or white
    Size:
    40*31*21mm
    Port:
    FOB Shenzhen
    Type of Payment:
    30% deposit,70% balance before shippmet by T/T
    Minimum Order Quantity:
    5000pcs
    Products Status:
    Stock
    Package:
    Yes
    Customised:
    Yes
    Interface Type:
    USB 2.0
    Description
    Contact Supplier
    Description
    • Input: 90-264V AC/47-63Hz
    • Output: 5V DC, 2A
    • Safety approvals: UL, CE
    • AC plug type: AU/US plug
    • DC connector: USB 5V 2A
    • Protection:

    Short-circuit protection, over-current protection and over-voltage protection
    MTBF (mean time between failures): 50,000 hours
    Warranty: 1 year

    Functions:

    Energy efficiency: Ⅴ/VI
    Line regulation (full load): ≤5%
    Load regulation: ≤5%
    Ripple and noise: ≤100mV
    Hold-up time: 20ms (220V AC, typical)
    Rise time: 50ms full load (typical)

    Temperature coefficient: <±0.03%/°C
    Withstand voltage: input&output 3kV AC/minute, input-outside case 3kV AC/minute
    Insulation resistance: ≥100mΩ (500V DC)
    Operating temperature: 0 to 45°C
    Testing:

    Burn-in test: 4H x 80-100% rated load at 40 ±5 degrees
    MTBF: at least 50,000 hours at 25 degree, full load
    Height: 1m, product should be fall off on the 20mm thick hardwood
    Average fault-free times under 25% maximum working load
    Average fault-free time 50,000 hours (as per IEC60950 standards)

    Packing details:

    Free PE bag for each power adapter
    White box packing: USD 0.1-0.2
    Gift box: $0.25 to 0.50

    Delivery details:

    UPS/FedEx/DHL/by sea
    Delivery lead-time: 15 days for 3000-5000 pieces
