MCU Chip-Set

32 ARM MCU

Protocol type

UART/TTL

Size

7.0 inch

Resolution

1024*600

Storage Space

16Mbit

Font library

Built-in vector font, edge anti-aliasing processing, including any size bitmap ASCII, GBK, GB2312,

Photo storage

Support JPEG, PNG (half through/full through) compression, support arbitrary size image storage, support image rotation, zoom,
zoom and other functions. The image compression ratio is different, this value will float up and down;

color

65K，16Bit RGB

voltage

5.0V /3.3V

Power consumption

Back Light Power ON：3.5W； Back Light Power off：1.6W

Communication interface

RS232/TTL(Default TTL)

Interface Specification

PH2.5-6P

Images download

UAR

PC software

YS_UI_Editor_V3.0

LCD type

TFT 7.0 inch tft

Back light

LED

brightness（cd/m²）

450

Back light life time（h）

>20,000

contrast

400:1

View Angle（L/R/T/B）

70/70/70/70
