NXpower  Groundbreaking Wireless Charging Technology
As a member of A4WP iCirround is at the forefront of wireless charging technology. Working as exclusive partner of Qualcomm and Intel to get wireless charging to the mass consumer market.

Features
TX
-Powered by latest magnetic resonance technology
-Charge multiple devices at the same time
-Freedom of placement
-Smart charging with auto-detection and performance adjustment.
RX
-Multi mode of A4WP and Qi, PMA
-Compliance with smart phone existing wireless applications
-Cool, thin and fashion design

TX–T12Class 2 – A4WP
Model No. T12
Input Power Adapter DC12V~18V,1Amax (18V)
Watt 10W max
Working frequency 6.78 MHz ± 15kHz
Transmission Distance <20mm
Power I/O DC Jack
Wireless Communication BLE
Net Weight 71 g
PCBA (LxWxT) 153x39x13.5 mm
Resonator(LxWxT) 92x92x10 mm

RX–R23Category 3-A4WP; Qi Compatible
Model No. R23
Output Power DC3V~5V,1Amax
Watt Both 5W max
Working frequency A4WP:6.78 MHz ±15kHz
Qi:100~200KHz
Transmission Distance A4WP<20mm
Qi:<1mm
Wireless Communication A4WP:BLE
Qi:Generic RF100~200KHz
Net Weight 8 g
PCBA (LxWxT) 45x20x2 mm
Resonator(LxWxT) 73x55x0.76mm
