Backlight System Ultra Thin LED Panel Module DC12V
Production Lead Time:
7 - 20 day(s)
Model No.:
RX-ALF3528-33-6060
Brand:
Xinelam
Colour:
Cool white, Neutral white, Warm white
Size:
600x600x3mm
Port:
Zhongshan
Type of Payment:
T/T, Western Union, PayPal
Minimum Order Quantity:
1 piece
Voltage(V):
DC12V
Wattage(W):
22W
Power Source:
AC
Use:
Lightbox backlight
Description
Contact Supplier
Description
• Backlight system Ultra thin LED Panel Module DC12V
Application:
• Advertising light box backlit
• Commercial lighting project
• Ceiling light source
• Outdoor or Indoor applications
• Replacement fluorescent tube troffer for commercial and office application
• Item No: RX-ALF3528-33-6060
• Dimension: 600x600x3mm
• Power: 22W
• Operated voltage: DC12V
• Light efficiency: 100Lm/w
• Light chips: SMD3528(324pcs)
• CRI: >80
• Ultra thin: 3mm
• Custom size: Accepted
• Viewing angle: 120degree
• Waterproof rated: IP67 Rating
• Certification: CE RoHs FCC
• Operated temperature: -30-50 degree
• Optional color(CCT): ww(2800-3200k),nw(3800~4250k),cw(6000-6500k)
• Life Span: >50.000hrs
• Warranty: 3years
• Patent No. ZL200820131053,200820132702
Features:
>Safe and reliable voltage DC12V
>Quick and simply installation
> Self-cooling, no additional heat sink required
>Homogeneous illumination without shadows
>Different length, power cost, wattage, brightness optional
Application:
• Advertising light box backlit
• Commercial lighting project
• Ceiling light source
• Outdoor or Indoor applications
• Replacement fluorescent tube troffer for commercial and office application
• Item No: RX-ALF3528-33-6060
• Dimension: 600x600x3mm
• Power: 22W
• Operated voltage: DC12V
• Light efficiency: 100Lm/w
• Light chips: SMD3528(324pcs)
• CRI: >80
• Ultra thin: 3mm
• Custom size: Accepted
• Viewing angle: 120degree
• Waterproof rated: IP67 Rating
• Certification: CE RoHs FCC
• Operated temperature: -30-50 degree
• Optional color(CCT): ww(2800-3200k),nw(3800~4250k),cw(6000-6500k)
• Life Span: >50.000hrs
• Warranty: 3years
• Patent No. ZL200820131053,200820132702
Features:
>Safe and reliable voltage DC12V
>Quick and simply installation
> Self-cooling, no additional heat sink required
>Homogeneous illumination without shadows
>Different length, power cost, wattage, brightness optional
