C106 Semi-Conductive/Insulation/Electrometric Insulation Tri-Layer Heat Shrink Tube
Production Lead Time:
28 day(s)
Model No.:
C106
Brand:
UPM heat shrink
Colour:
black-red-black
Type of Payment:
T/T, D/P
Description
Contact Supplier
Description
• C106 semi-conductive/insulation/electrometric insulation tri-layer heat shrink tube
Features
• Cross-linked heavy wall tubing
• Operating temperature: -55~105℃
• Tri-layer design with high recovery forces
• Shrink temperature: 135-150℃
• Co-Extrusion technology
• Voltage class: 10-35 KV
• Eliminates partial discharge
• Halogen free ,RoHs Compliant
• Enable the joint to follow the thermally induced dimensional changes of cable insulation.
Typical application
• Ideal for insulation of power cable joint up to 42KV
Ordering
• Standard color : Black/Red/Red
• Standard packaging is 1m/pc or 1.22m/pc
• Please specify specification, quantity when ordering
Cross reference
• Raychem/ Tyco: ERIT/ERIC/ERIH Reference
UPM C106
35/13
45/17
50/21
63/26
75/34
85/34
95/42
110/52
125/62
