Cabinet Lighting LED Lighting Lamp LED 025 Series, 5w LED, Easy to Install Cabinet Lighting
Production Lead Time:
5 day(s)
Model No.:
LED 025
Brand:
STEGO/ neutral/OEM/neutral
Colour:
cool white
Size:
351mmX52mmX32mm
Port:
Ningbo/Shanghai
Type of Payment:
T/T, Western Union,MoneyGram,Paypal/Escrew
Minimum Order Quantity:
1
Voltage(V):
AC230v
Certification:
CCC, RoHS
Wattage(W):
5w
Warranty:
1 year
Light Source:
led
Body Material:
Aluminum, Polycarbonate (PC)
Is Dimmable:
No
Power Source:
AC
Including Bulbs:
Yes
Switch Type:
Rocker Switch
Description
Contact Supplier
Description
Wide voltage range
Integrated power unit
Daisy chain
Long-lived and maintenance-free by LED technology
Magnet or screw fixing
On/off switch or movement sensor
The lamp series LED 025 is suitable for all types of panels and enclosures, especially where space is at a premium. The lamps have a very long service life thanks to the use of LED technology. They are available with powerful non-slip rubberized magnets allowing them to be quickly positioned in any steel enclosure. Alternatively they can be fixed mechanically. The power output allows up to 10 lamps to be connected to each other (daisy chain). Both the power input and output connectors snap lock into their sockets. With the integrated power unit and the plugs the lamp can quickly be connected.
Technical Details Power consumption max. 5W
Luminosity 290Lm at 120° (870Lm at 360° or equivalent 75W light bulb)
Lamp type LED, angle of radiation 120°
light color: daylight, color temperature: 6,500K
Service life 60,000h at +20°C (+68°F)
Connection 2-pole connector with snap lock
AC: max. 2.5A / 240VAC, color: white
DC: max. 2.5A / 60VDC, color: blue
Mounting magnet fixing or screw fixing (M5), torque 2Nm max.,
250mm centers
Casing plastic, transparent
Dimensions see drawings
Operating/Storage temperature -30 to +60°C (-22 to +140°F) / -40 to +85°C (-40 to +185°F)
Operating/Storage humidty max. 90% RH (non-condensing)
Protection type/Protection class IP20 / II (double insulated)
Approvals
Important note: Connectors and cables for electrical connection are not included in the delivery. These parts can be ordered separately (see Accessories, next page). Sets, consisting of lamp and accessories, are available on request.
Art. No. Magnet fixing Art. No. Screw fixing Operating voltage Switch Weight (approx.)
02540.0-00 02540.0-01 100-240VAC, 50/60Hz (min. 90VAC, max. 265VAC) on/off light switch 0.2kg
02540.1-00 02540.1-01 24-48VDC (min. 20VDC, max. 60VDC) on/off light switch 0.2kg
02541.0-00 02541.0-01 100-240VAC, 50/60Hz (min. 90VAC, max. 265VAC) PIR movement sensor¹ 0.2kg
02541.1-00 02541.1-01 24-48VDC (min. 20VDC, max. 60VDC) PIR movement sensor¹ 0.2kg
approx. 5 min. fixed switch-on duration
Integrated power unit
Daisy chain
Long-lived and maintenance-free by LED technology
Magnet or screw fixing
On/off switch or movement sensor
The lamp series LED 025 is suitable for all types of panels and enclosures, especially where space is at a premium. The lamps have a very long service life thanks to the use of LED technology. They are available with powerful non-slip rubberized magnets allowing them to be quickly positioned in any steel enclosure. Alternatively they can be fixed mechanically. The power output allows up to 10 lamps to be connected to each other (daisy chain). Both the power input and output connectors snap lock into their sockets. With the integrated power unit and the plugs the lamp can quickly be connected.
Technical Details Power consumption max. 5W
Luminosity 290Lm at 120° (870Lm at 360° or equivalent 75W light bulb)
Lamp type LED, angle of radiation 120°
light color: daylight, color temperature: 6,500K
Service life 60,000h at +20°C (+68°F)
Connection 2-pole connector with snap lock
AC: max. 2.5A / 240VAC, color: white
DC: max. 2.5A / 60VDC, color: blue
Mounting magnet fixing or screw fixing (M5), torque 2Nm max.,
250mm centers
Casing plastic, transparent
Dimensions see drawings
Operating/Storage temperature -30 to +60°C (-22 to +140°F) / -40 to +85°C (-40 to +185°F)
Operating/Storage humidty max. 90% RH (non-condensing)
Protection type/Protection class IP20 / II (double insulated)
Approvals
Important note: Connectors and cables for electrical connection are not included in the delivery. These parts can be ordered separately (see Accessories, next page). Sets, consisting of lamp and accessories, are available on request.
Art. No. Magnet fixing Art. No. Screw fixing Operating voltage Switch Weight (approx.)
02540.0-00 02540.0-01 100-240VAC, 50/60Hz (min. 90VAC, max. 265VAC) on/off light switch 0.2kg
02540.1-00 02540.1-01 24-48VDC (min. 20VDC, max. 60VDC) on/off light switch 0.2kg
02541.0-00 02541.0-01 100-240VAC, 50/60Hz (min. 90VAC, max. 265VAC) PIR movement sensor¹ 0.2kg
02541.1-00 02541.1-01 24-48VDC (min. 20VDC, max. 60VDC) PIR movement sensor¹ 0.2kg
approx. 5 min. fixed switch-on duration
