Product Description

RT8620-AL originally researched and developed by KWT, die-casting highrank aluminum integrated heat sink. Driver shell of fire-proof PC material, international top COB CITIZEN chip, combined with KWT exclusive optical system of glare-free lens , standard driver originally researched and developed by KWT, stable specifications, glare-free, good heat sink, brilliant quality, more than 40,000 hours life span.

Technical Parameter

Nominal wattage                                                   20/30W

 Input Voltage                                                      220-240V

 Color temperature                                              3000K/4000K/5000K

Color rendering index                                         Ra>90

Beam angle                                                         15°/30°/45°

3000K Luminous flux                                        15° 209lm/30° 222lm/45° 237lm

 4000K Luminous flux Product color                     15° 213lm/30° 228lm/45° 246lm

Type of protection                                              IP20

Operation temperature                                     - 20℃- 50℃

Warranty                                                           5 years

Product features

·High Ra﹥90, Low SDCM﹤3

·High efficacy, high illuminance

·Glare-free design, perfect light spot and accurate beam

 angle, make surroundings of comfortable illumination

·Refined components and design, guarantee a long life

 span of over 40,000 hours ·Rotatable horizontal 355° and vertical 90°

·Driver box designed close to rail for a neat and elegant

 visual feeling

Installation

1.Please install the related track rail before install the light

 (Picture one)

2.Aim the track head to the track rail then push up, make sure

 the track head are total match into the track rail(Picture two)

3.After install the track head into the track rail, rotate the connector

 spindle 90 as below(Picture three)
