Production Name | Facial recognition Bus Validator NFC card bus fare collection system with QR code Bus fare payment Machine with voice broadcast |
Model No. | GC158 |
Application industry | Bus Transportation Cashless Payment Collection System, bus fare collection validator, Bus Ticketing Machine, Prepaid card pos payment terminal, automatic ticketing bus fare collection validator. |
Application software | OS installed, free SDK, bus validator apps not included |
2D code decoding | Built-in 2D code decoding software, based on Android |
Operation System | Android 6.0 / Android 7.1.2 / Android 10 |
CPU | Unisoc SL8541E, ARM Cortex-A53, quad core, 1.4GHz |
DDR | 2GB RAM LPDDR3 |
Storage | 16GB EMMC |
LCD display(either-or) | Landscape mode: 7 inch RGB LCD, 1024*600 pixel |
or Portrait mode: 5 inch RGB LCD, 480*800 pixela |
Driver's display | 8 segment 4 bit LED |
Touch panel | no touch as default |
Barcode scanning module | 1D code: UPCA,UPCE0,Code 11,Codabar,Matrix2of5,Industrial25, RSS14,RSSLimited,RSSExpanded, MSIPlessey,UPCE1,EAN13,EAN8, CODE39,CODE 93,CODE 128, ISBN13,INTERLEAVED 2 of 5; |
2D code: PDF417 DATAMATRIX
QRCode |
RFID reader(NFC) | 13.56MHZ contactless, ISO/IEC14443A/B, ISO/IEC 15693, MIFARE and FeliCa specifications. |
Ai Facial Recognition Camera | (Optional)Binocular camera RGB+IR 2.0M Depth camera,living body detection |
Speaker | High effient DSP processing, SD sound effect, 3W mono output |
key/button | Enter, Up, Down, Back in the bottom |
Commucation module (4G module can be changed to user country/region band) | LTE-FDD: B1/B3/B5/B7/B8/B20/B28 |
LTE-TDD: B38/B40/B41 |
WCDMA: B1/B5/B8 |
GSM/EDGE: 900/1800 MHz |
Bluetooth 5.0 |
GGNSS: GPS + GLONASS or GPS |
Interface (may vary for different product batch,OEM available) | USB OTG x 1 |
Comport(RS232) x 1, ethernet plug or RS485 |
DC x 1 (Φ12MM aircraft connector, 10-40V, 2.5A) |
GPS antenna plug: x1, RP-SMA plug |
SIM card x3, PSAM x1, more SIM card slot and PSAM slot is available upon customization |
Accessories | Car cigarette lighter socket, 10-40V, 2.5A
|
(Optional)7.4v 2400mAh polymer battery pack, when there is no transmission, the barcode scanning time is 12hours. |
Working temperature | -10℃~50℃ |
Storage temperature | -40℃~80℃ |
Humidty | 95% without sticky |
ESD protection | 12KV |
