Custom Portable Battery System for Wellness and Physiotherapy Devices | Fitness & Body Building

Dongguan Shanze New Energy Technology Co Ltd

Enquire

Compare & Bulk Enquire

Custom Portable Battery System for Wellness and Physiotherapy Devices

US $20.00 - US $30.00

Production Lead Time:

15 day(s)

Shipping Method:

sea shipping/air shipping

Customised:

Yes

Battery Type:

Lithium Ion

Size:

7S8P

Material:

ABS -+ PC

Weight:

6kg

Capacity:

20ah

Output Power:

800

Model No.:

18650

ESD Test:

±4KV

"Storage Temperature :

"-5°C~35°C "Storage capacity should be 40%~50% full charge capacity 40%~50%"

Capacity :

"Typical: 20.8Ah Min: 20Ah

Charge Voltage:

29.4V

Impedance :

≤200mΩ

Description

Contact Supplier

Custom Rechargeable Battery Packs for Sports Recovery and Physiotherapy Equipment

No 序号	Item 内容	Parameter 参数	Remark 备注
1	Rating Voltage 标称电压	25.2V
2	Capacity 标称容量	Typical: 20.8Ah 典型：20.8Ah Min: 20Ah 最小：20Ah	0.2C discharge after full charge. 完全充电后用0.2C放电至截止电压的容量。
3	Charge Voltage 充电电压	29.4V
4	Impedance 内阻	≤200mΩ
5	Charging Mode 充电方式	C.C/C.V. 恒流/恒压方式	Constant Current / Constant Voltage 恒流/恒压视电池电压转换
6	Charging Method 充电方法	Standard Charging 标准充电 Fast Charging 快速充电	Charging Current 4000mA 充电电流：4000mA Charging Current 10000mA 充电电流：10000mA
7	Charging Time 充电时间	Standard Charging 标准充电：5Hours Fast Charging 快速充电：2.5Hours
8	Standard Discharge Current 标准放电电流	20.0A
9	Max Discharge Current 最大放电电流	40.0A	-10°C ~ +60°C
10	End of Discharge Voltage 放电截止电压	20.16V
11	Overcharge Voltage 过充电保护电压	4.25±0.05V
12	OverCurrent 过电流保护	30-40A
13	Short Circuit 输出短路保护	Activation recovery after the protection of the short circuit load 保护后撤销短路负载激活恢复
14	Operating Consumption Current 工作消耗电流	≤20μA
15	Operating Temperature 工作温度	Charging 充电：0~45°C Discharging 放电：-20~60°C
16	Storage Temperature 贮存温度	-5°C~35°C Recommend 推荐 (25±5°C)	Storage capacity should be 40%~50% full charge capacity 贮存时应充电至容量的40%~50%
17	ID Resistor ID 电阻	/
18	NTC Resistor NTC 电阻	/
19	ESD Test 静电测试	±4KV
20	Cycle Life 循环寿命	300 cycle 300次

Please send us your device voltage, capacity, working current, connector type, dimensions and expected quantity. Our engineers will recommend a suitable battery solution
