Product Features

• Isolated adjustable power color temperature LED driver
• Supports DALI-2, push DIM control , push CCT control
• Usable as DT6 (2-channel) or DT8 (tunable white) driver
• Current adjustment via NFC
• Supports i-Data function(DALI part 251,252,253)
• Output current 500…1050mA
• Max output power 44W
• DC emergency
• Flicker-free
• Current output default value 100%
• For luminaires with protection class l, ll


  Description

• Constant current driver with wide operating windows
• Supports DALI-2, push DIM and push CCT
• Supports NFC readers for precise setting and control of multiple functions
• Supports two independent DT6 or one DT8 output
• Smooth colour temperature setting and dimming with dimming range 1-100% (amplitude dimming)
• Equipped with i-Data (30W, 44W, 60W): enabling data management according to DALI parts 251, 252 and 253
• The DC emergency mode adjusts the current to 15% by default (adjustable), applies to 30 W, 44 W, 60 W versions
• Loop through connection comply with 2.5 mm² engineering cable entry specifications
• Standby power consumption ≤ 0.3 W (30-60 W), < 0.5 W (20 W), meets ErP energy efficiency certification
• Packing unit programming: configure a large number of drivers in parallel via NFC
