DTF65 electric control valve
Production Lead Time:
10 day(s)
Shipping Method:
AIR
Customised:
Yes
Model No.:
DTF65
Application:
Suitable for working media such as high purity gaseous
Description
Contact Supplier
Description
The DN25 vacuum valve is suitable for high-purity gases such as HF etc., with a right angle structure, the valve body is made of 316L forgings and sealed with metal bellows; By using a high-precision motor transmission mechanism and a specially developed intelligent controller, precise control of the pressure and flow behind the valve can be achieved. The special design of the valve core enables equal percentage adjustment of flow characteristics.
PARAMETERS:
| Model | DTF-65 |
| Seat diameter size | 65mm |
| Max. working pressure | 0.4 MPa |
| Driving Type | 380/220V、50Hz |
| Temperature range | 0℃～80℃ |
| Flow coefficient (Kv) | 0.1～10m³/h |
| Vacuum degree | 1×10-3mmHg |
| Switching time | ≤8s |
| Leak rate | internal：＜1×10-7Pa·L/s external：＜1×10-6Pa·L/s |
MAIN COMPONENT MARERIALS:
316L/316L(VIM+VAR)+HC
OPTIONS:
Electrochemical polishing
Cleanroom assembly (Class 100 cleanroom)
