Digital Ballast
Share this page
Production Lead Time:
30 day(s)
Model No.:
SK-1000
Brand:
Sunkan
Colour:
Green, Silver, Black, Orange, Purple
Port:
Shanghai, Ningbo, Shenzhen
Type of Payment:
T/T, L/C
Minimum Order Quantity:
100
Description
Contact Supplier
Description
  • Model: SK-250, SK-400, SK-600, SK-1000.
  • Voltage input range: 90V AC~260V AC.
  • Rating V. in: 120/240V AC.
  • Frequency type: high frequency, >30kHz.
  • Input frequency: 50Hz~60Hz.
  • Strike voltage: <5kV.
  • Required lamp voltage: 85~130V & 245~300V.
  • Lamp type: HPS/MH.
  • Power factor: >0.99.
  • Efficiency: 93% (max).
  • THD: <10%.
  • Dimming function: 50%-57%-100%-110%/super lumens.
  • Current crest factor: <1.5.
  • Output frequency: >30kHz.
  • Protection of short circuit: yes.
  • Protection of open circuit: yes.
  • Protection of ignition failure: yes.
  • Protection of thermal: yes.
  • Protection of end of lamp life (EOL): yes.
  • Max. lamp distance from ballast: <15m.
  • Operating temperature range: -30℃~+50℃.
  • Max. case temperature (TC): 90℃.
  • Dimension (L x W x H) mm: 230 x 112 x 70, 287 x 112 x 70, 343 x 112 x 70, 386 x 112 x 70.
