ESD Simulator Guns
US $2999.00 - US $5999.00
Production Lead Time:
20 day(s)
Shipping Method:
By express
Application:
testing instrument
Brand:
LISUN
Model No.:
ESD61000-2
Description
Contact Supplier
Description
What is a ESD test?
The static electricity generated by the human body to the object or between two objects may cause the electrical and electronic equipment circuits to malfunction or even be damaged. The ESD generator is designed for the withstanding ESD performance measurement for the assessment of electrical and electronic equipment. ESD61000-2/ESD61000-2A has a LCD touch screen in both English and Chinese.
What is an esd simulator gun used for?
Electrostatic discharge simulator is highest electrostatic voltage can be up to 30 kv, which is enough to cover the most severe standard grade of electrostatic voltage requirement (the voltage requirements of the level 4 air discharge electrostatic is 15 KV). The ESD test gun can be used for the most of electrical and electronic equipment for electrostatic discharge test, and also can ensure comparability and reproducibility of test.
Specification:
| LISUN Model | ESD61000-2 | ESD61000-2A | ESD61000-2C |
| Output Voltage | 0.1~20kV±5% | 0.1~30kV±5% | |
| Output Polarity | Positive, Negative or Automatic Switching | ||
| Discharge Capacitor/Resistor | 150pF/330Ω (Replaceable) | 150pF/330Ω, 150pF/2000Ω, 330pF/2000Ω, 330pF/330Ω (Replaceable) | |
| Current Rise Time | 0.6~1ns | ||
| Testing Functions | Single Test, Count Test, 20PPS, IEC level, Programmable Mode, Custom Mode, Contact Discharge, Air discharge, Interval Discharge | ||
| Trigger Mode | Manual/Auto | ||
| Discharge Numbers | 1~9999 | ||
| Discharge Repetition | 0.05s~99.99s | ||
| Discharge Tip | Contact Discharge Tip, Air Discharge Tip | Contact Discharge Tip, Air Discharge Tip, 30mm Diameter Air Discharge Tip | |
| Working Power | AC220V (Option is 110V)±10%, 50/60Hz | ||
| Standards | IEC/EN 61000-4-2 (GB/T 17626.2) | Automotive Electronics ISO 10605 (GB/T 19951) IEC/EN 61000-4-2 (GB/T 17626.2) | |
Calibrate Report (The more details can click here: ISO17025 CNAS iLac-MRA Calibrate Certificate):
| Output Voltage (kV) | First Peak Current (A) | Current at 30ns (A) | Current at 60ns (A) | Rise Time (ns) |
| 2 | 7.29 | 4.1 | 2.2 | 0.93 |
| 4 | 15.4 | 7.9 | 4.3 | 0.97 |
| 6 | 23.2 | 12.1 | 6.5 | 0.97 |
| 8 | 29.4 | 16.2 | 9.3 | 0.89 |
| -2 | 7.39 | 3.5 | 2.3 | 0.92 |
| -4 | 15.5 | 7.7 | 4.3 | 0.89 |
| -6 | 23.4 | 11.9 | 6.3 | 0.9 |
| -8 | 31.8 | 16.1 | 8.2 | 0.9 |
Suggestions 1:
We suggest you choose LISUN ESD-DESK ESD Gun Test Desk was designed and produced according to Automotive Electronics ISO 10605 (GB/T 19951) and IEC/EN 61000-4-2 (GB/T 17626.2), it works with ESD61000-2/ESD61000-2A/ESD61000-2C Electrostatic Discharge Gun. The ESD-DESK already includes the followings: Test Table (After Assembly diamention: Length1600*Width800*Height800mm), Reference Metal Grounding Plate (L2800*W1800*Thickness1.0mm), Vertical Coupling Plate (L500*W500*T1.0mm), Horizontal Coupling Plate (L1600*W800*H1.0mm), Insulating Pad (L1450*W600*H0.5mm) and 470K Resistance Cable (L1400mm).
