Fiber Optic Light Engine
US $122.00 - US $128.00
Production Lead Time:
15 day(s)
Shipping Method:
Express
Brand:
Minar
Model No.:
LER-4121DMX
Voltage:
AC 110V-220V
LED:
RGBW, 4*12W
Control:
DMX512/RF remote/Manual
IP Rating:
IP20
Housing Material:
Aluminium
Description
Contact Supplier
Description
Model: LER-4121DMX
Features: 50W RGBW, Absolute Noice-Free
Fiber strands capability: It has one port with a maximum diameter of 30mm. The port is capable of 1250pcs of 0.75mm fiber strands, which are suitable for a ceiling of 18 square meters, an average of 70 tails per square meter. The maximum length of fiber tails this light engine supports is about 18 meters.
One of the outstanding features of LER-4121DMX is its quietness. There is no motor or disc inside the light engine. For some special locations, such as the museum, art gallery, where the noise is not tolerable. LER-4121DMX will be the perfect choice. Its power is 50W with 12W for each color. There is also a 15-key remote controller for dimming and inbuilt programs.
| Model | LER-4121DMX |
| Voltage | 110V-220V |
| LED Color | RGBW |
| Power | 40W |
| Light Source | 4*12W |
| Life of LED | 35000H |
| Aperture | Φ30mm/ Φ28mm/ Φ24mm/ Φ20mm ( Standard Aperture is Φ28mm ) |
| Fiber Optics | Φ0.75mm x 1250 pcs ( Φ30mm ), (not included in the quotation) |
| Wheel/Fans | NO |
| Size | L267 X W140 X H80(mm) |
| Net Weight | 2 kg |
| Remote | RF, RC-15 |
