FleXCite Series - Dual-Bend - NS-161-2323ZZ | Indoor Lighting

General Lighting Innovation Limited

Enquire

Compare & Bulk Enquire

FleXCite Series - Dual-Bend - NS-161-2323ZZ

Part No.:

NS-161DX24VAW-14-2323FC

Style:

Dual-Bend (White)

Dimension:

W23xH23mm [W0.9xH0.9in.]

Max. Run Length & Max. Shipping Length:

5M [16.4ft.] & 30M [98.4ft.]

Increment:

Free-cutting to be any length

LED Type:

SMD 2835

LED Qty:

120LED/M [36LED/ft.]

Voltage:

DC24V

Power:

14W/M [4.27W/ft.]

CCT/Wavelength:

2700K±120K 3000K±150K 3500K±300K 4000K±300K 5000K±400K 6000K±500K

Brightness@4000K&CRI80:

907lm/M[277lm/ft.]

Light Efficacy@4000K&CRI80:

65lm/W

Brightness@4000K&CRI90:

771lm/M[235lm/ft.]

Light Efficacy@4000K&CRI90:

55lm/W

Beam Angle:

120°

IP&IK Rating:

IP67 [Wet] & IK07

Description

Contact Supplier

Features
-

1. Flexible dual-bend supports both top-bend and side-bend, available to build many signages and arts in wave pattern.
2. Uniform, dot-free, smooth and comfortable luminary up to 5M [16.4ft] run length.
3. Multiple versions available in White, CCT, D2W, RGB, RGBW, SPI RGBW(IC in UCS8904) and DMX RGBW(IC in TM512AC) color for various of scenes.
4. Field cuttable and assembly with endcap sealed by glueing process.
5. Customized length with overall appearance in the same size by die-casting process.
6. IP67 for indoor or outdoor usage.
7. Dimmable available with PWM signal.
8. Compared with traditional fragile glass and harden/yellowing easily PVC sheathing material, silicon extrusion technology is an advanced process, with high-efficiency production capacity and environmentally-friendly characteristics. Additionally, with high grade appearance, soft bend flexibility, strong impactresistant and high weather resistance.
9. Up to 50,000h LED lifespan and 5 years warranty.
10. UL & TUV-CE approval.
