Characteristics:

Rated Input Voltage: AC220-240V 50HZ( Power factor measured at AC230V and full load)

Model No.            Constant Output Voltage        Load              λ               Ta               Tc                        L*W*H                   Approval

GPD100-12VF                DC 12V                     100W(230V)      0.9         -20-45℃       90℃             323*30*17mm          TUV pending

GPD100-24VF              DC 24V                        75W(120V)       0.9         -20-45℃       90℃             323*30*17mm          TUV pending

Features:

*Independent driver for constant voltage LED light

*Terminal block for quick connection

*Class II protection against electric shock from direct and indirect contact

*SELV output

*Open sircuit, short sircuit, over load and over temperature protection

*Auto restart after fault conditions removal

*Efficiency ≥  90%（AC 230V, full load）
