Characteristics:

Rated Input Voltage: AC220-240V 50HZ( Power factor measured at AC230V and full load)

Model No.          Constant Output Voltage       Load         λ               Ta               Tc                        L*W*H             Approval

GPD20-12VF                  DC 12V                        0-20W      0.5         -20-45℃       85℃             167*45*14.5mm       TUV

GPD20-24VF                  DC 24V                        0-20W      0.5         -20-45℃       85℃             167*45*14.5mm       TUV

Features:

*Independent driver for constant voltage LED light

*5 way socket on secondary side directly for easy connection

*Terminal block for quick connection

*SELV output

*Open sircuit, short sircuit, over load and over temperature protection

*Auto restart after fault conditions removal

*Efficiency ≥  83%（AC 230V, full load）
