HVE series:Isolated Street Light LED Drivers
Brand:
SUNCOM
Feature:
INPUT VOLTAG: 200-277V ELECTRICAL PERFORMANCE PARAMETERS: THD < 10%/PF > 0.95 SURGE PROTECTION GRADE: 6/10KV (≤75W:4/6KV) IP GRADE: IP67 WARRANTY: 5 years
Light Source:
LED
Power Source:
AC Power
Size:
109*61*33MM,141*61*33MM,179*69*36MM,ETC.
Model No.:
HVE-30H-38A,HVE-75H-38A,HVE-100H-38A,ETC.
Weight:
0.365KG, 0.47KG, 0.532KG, 0.89KG,ETC.
Customised:
Yes
Is Dimmable:
Yes
Description
Contact Supplier
Description
Input voltage: 200-277
THD<10%, PF>0.95
Class I type for insulation
Constant current output ,with power limitation for control mode
Efficiency: 90%（Typ.）
Surge protection: 6/10KV
Metal material case, IP67
Protection: UVP/SCP/OVP/OTP
Global certifications: CCC/CE/CB
Dimming function: 3-in-1 dimming (1-10V dimming, resistance dimming, PWM dimming)
Output current is dimmed by external potentiometer (Only Type A)
Output current is dimmed by Isolated 3 in 1 dimmer（Only Type B）
Working temperature: -40 ~ 55℃
Safety case temperature: -40 ~ 90℃
Output current is dimmed by Isolated 3 in 1 dimmer（Only Type B）
Working temperature: -40 ~ 55℃
Safety case temperature: -40 ~ 90℃
Storage temperature: -40 ~ 80℃
Warranty: 5 years
Warranty: 5 years
