Features

• Modular dimming mechanism
• Soft start function to protect the lamp
• Over-temperature, over current protection
• Provide optimised dimming of LED based lamps and drivers
• Immune to high frequency (ripple) signal injection on mains supply
• With Min. and Max. brightness adjustment, to achieve the optimum dimming range for a particular load


Rated Voltage

AC 220-240 V / 50Hz

Connected Load

5VA - 400VA (1 - 15 LEDs, 150W max.)

Minimum Load

5VA

Dimming Method

Trailing edge phase control

Push button and ON/OFF switch

Type of Loads

Dimmable LED Light

220 - 240V AC Incandescent lamps

Connection

Screw terminals
