★ Strong waterproof : IP68 Waterproof class the highest level /any Weatherproof / Moisture-proof/Dust-proof/ anti-UV, Can be immersed up to 50 meters in water to protect your electricity
★ High-quality materials : PA66,UL94-V0, high temperature resistance, anti-corrosion, sunscreen, ideal for outdoor, home, garden, underwater, underground
★ Easy to install : Small volume and quick installation, can be installed in any place where it needs
★ Wide Usability : Suitable for kinds of outdoor lighting, weatherproof lighting, underwater lighting, LED billboards, tunnel lights, outdoor display. Further applications in coastal, river, sea or underwater engineering, underground engineering, mining engineering, solar-wind power, solar water heaters, various machinery and equipment.


Test Standard

• IEC60998-2-1:2004
• IEC62444:2013
• IEC60529:1991+A1:2000+A2:2013

Technical Information

• 250V/450V, PTI 250, T85, IP68 at 5 bar 24A

Material Specification

• Housing: PA66, UL94-V0
• Sealing Gasket: Silicon
• Contact: Brass, nickel plated
• Color: Black

Mechanical Specification

• Termination: Screw fixing
• Wiring cable spec: φ5mm to φ14mm
• Warranty 3 years limited
