General:

• Frequency : Tx144-148MHz

                            Rx 136-174Mhz (guaranteed range : 144-148Mhz)

• Mode : F3E, F2D, F7W**Optional UT-118 Required
• Number of memory Ch. : 207 (incl. 6 scan edges and 1 call)
• Operating Temp. Range : -10°C to +60°C; +14°F to +140°F
• Frequency stability : ±2.5 ppm (-10°C to 60°C)
• Power supply requirement : 7.2V DC (6.0-10.3V DC acceptable; Icom's battery pack only)
• Antenna impedance : 50Ω (BNC)
• Dimensions(Projections not included) :54 × 139 × 37.5 mm;
• Weight (approx.) : 390g; 13.8oz (w/ant. and BP-222N)

Transmitter:

• Output power (at 7.2V DC) : 7.0/4.0/0.5W (High/mid/low)
• Spurious emissions : Less than -60dBc
• Max. freq. deviation : ±5.0/±2.5 kHz (Wide/narrow)
• External Microphone connector : 3-conductor 2.5(d)mm (1/10") / 2.2kΩ

Receiver:

• Receive system : Double conversion superheterodyne
• Intermediate freq. : 46.35 MHz/450 kHz (1st/2nd)
• Sensitivity (typical) : 0.16µV (typ.; at 12dB SINAD)
• Squelch sensitivity : 0.11µV (typ.; threshold)
• Selectivity : More than 55/50dB (wide/narrow)
• Intermodulation : 65dB (typ.)
• Spurious and image rejection : 80dB
• Audio output power : 300mW with an 8Ω load
• Ext. speaker connector : 3-connector 3.5(d) mm (1/8”) / 8Ω
• Ext. Data connector : 3-connector 2.5(d) mm (1/10”)
