JP2050S
Brand:
JP Sensor
Colour:
Black
Size:
13.1 x 13.1 x 0.6 mm
Description
Contact Supplier
Description
JP2050S Capacitance Sensor
JP2050S is an ultra-thin CMOS fingerprint sensor whose thickness is only 0.6mm. Cermet-like coating provides up to 8H hardness and more than 10 million finger placements. Needless to say, anti-ESD protection above 30kV is equipped in JP2050S.
The JP2050S has an ultra-low power consumption less than 2mA in operation mode and 3uA in sleep mode, suitable for low power consumption application. 64-bit encrypted security key protects private fingerprint data from being stolen, which is the best option for personal privacy.
Resolution: 508DPI
Image capture Speed: 40 frames/sec
Sensor Type: Capacitance Type
Security Key: 64-bit
Hardness: 8H
Sensing Array: 192x192 pixels
Operating temperature: -20~60 ℃ / < RH 90%
Dimension: 13.1 x 13.1 x 0.6 mm (W x H x D)
JP2050S is an ultra-thin CMOS fingerprint sensor whose thickness is only 0.6mm. Cermet-like coating provides up to 8H hardness and more than 10 million finger placements. Needless to say, anti-ESD protection above 30kV is equipped in JP2050S.
The JP2050S has an ultra-low power consumption less than 2mA in operation mode and 3uA in sleep mode, suitable for low power consumption application. 64-bit encrypted security key protects private fingerprint data from being stolen, which is the best option for personal privacy.
Resolution: 508DPI
Image capture Speed: 40 frames/sec
Sensor Type: Capacitance Type
Security Key: 64-bit
Hardness: 8H
Sensing Array: 192x192 pixels
Operating temperature: -20~60 ℃ / < RH 90%
Dimension: 13.1 x 13.1 x 0.6 mm (W x H x D)
